The ElaProof BTR System is suitable for wooden and concrete surfaces!

An economical choice for sites where waterproofing is required or whose life cycle is to be extended. ElaProof coating is also ideal for waterproofing for balconies instead of bitumen felt, to avoid fire work. Typically, after ElaProof coating, the site is installed according to the customer’s wishes, e.g., a wooden rally, tile or object is painted with wear-resistant waterborne, breathable, and elastic paints. Exterior paints suitable for ElaProof include e.g., Kirjo Aqua (Teknos) and Panssari Akva (Tikkurila).

TIP! ElaProof is an elastic compound, so we recommend the use of C2 (TEF)(T), S2-classified fixing mortar for tiling. Its properties support the elastic properties of ElaProof.

Cross section of the floor structure

• A – final surface
• B – ElaProof H
• C – ElaProof Base fabric if required
• D – ElaProof Primer
• E – concrete / wood

A method that is used in sites with a lot of traffic and thus the need to keep the object clean. These sites include, e.g., stairs, balconies, terraces, warehouses and floors of technical facilities. The site is first coated with ElaProof, after which it´s treated with ELACOAT TopCoat. It increases the duration of wear and makes cleaning the surface easier.

TIP! For indoor use, please remember to use ElaProof Indoor, as it is an M1-approved product!

Cross section of the floor structure

• A – ELACOAT TopCoat
• B – ElaProof H
• C – ElaProof Base fabric if required
• D – ElaProof Primer
• E – concrete / wood

A method in which the site is first coated with ElaProof and then with ELACOAT TopCoat tinted in RAL color according to the customer’s wishes. There are currently over a hundred different RAL colors available, ten of which we have included in the standard range. The advantages of the method are e.g., a colored coating that supports the modern customer brand image. Thanks to the ELACOAT TopCoat RAL, the site is also easy to keep clean. The method is well suited for spaces that carry a lot of walking traffic daily and where the customer is expected to face a carefully considered brand image of the company.

Cross section of the floor structure

• A – ELACOAT TopCoat RAL
• B – ElaProof H
• C – ElaProof Base fabric if required
• D –  ElaProof Primer
• E – concrete / wood

A method where 3-color ElaProof Art&Deco Colour Chips or Art&Deco Colour Sand is sprinkled on top of the coating during ElaProof installation. The final surface is treated with ELACOAT TopCoat. The advantages of the method are e.g., waterproofing, a modern look and a topcoat make it easy to keep the item clean.

TIP! For indoor use, please remember to use ElaProof Indoor, as it is an M1-approved product!

Cross section of the floor structure

• A – ELACOAT TopCoat
• B – Art&Deco Colour Chips / Colour Sand
• C – ElaProof H
• D – ElaProof Base fabric if required
• E –  ElaProof Primer
• F – concrete / wood

A method in which the site is coated with the customer’s choice of ElaProof+SAND Floor Covering, where the ElaProof coating and sand are ready-to-use. The final floor surface is treated with colorless or RAL shade ELACOAT TopCoat.

ElaProof+SAND FLOOR COVERING is M1 approved. It is suitable for indoor and outdoor use e.g., terraces, stairs, balconies, and bathrooms. The tiled floor in the bathroom must be waterproofed with approved waterproofing for use under the ceramic tiles. This waterproofing must not be more than 10 years old during the coating phase, based on RIL 107-2012.

There are three grain sizes to choose from: fine (0.05-0.2 mm), medium (0.1-0.6 mm) and rough (0.7-1.2 mm). The final surface is pleasantly rough and comfortable underfoot, while reducing the risk of slipping. On top of the coating, we recommend ELACOAT TopCoat treatment to ensure that the site is easy to keep clean. Also remember the tinted ELACOAT TopCoat RAL topcoats, which give color to the surface if necessary.

Cross section of the floor structure

• A – ELACOAT TopCoat / RAL
• B – ElaProof+SAND * 2 treatments
• C – ElaProof H
• D – ElaProof Base fabric if required
• E –  ElaProof Primer
• F – concrete / wood
